Taramps MD 1200.1

Operation class Class D

Number of Channels 1

Version 1 ohms :

Maximum power @ 12,6 VDC - 1200W RMS ( 1 ohms )

Version 2 ohms :

Maximum power @ 12,6 VDC - 1200W RMS ( 2 ohms )

Maximum power @ 12,6 VDC - 800W RMS ( 4 ohms )

Version 4 ohms :

Maximum power @ 12,6 VDC - 1200W RMS ( 4 ohms )

Maximum power @ 12,6 VDC - 855W RMS ( 8 ohms )

Input Sensitivity 220mV

Signal to Noise Ratio >88dB

Frequency Response 10Hz ~ 20KHz (-3dB)

Crossover high pass (HPF) 10Hz ~ 80Hz (-12dB/8ª) Variável

Crossover low pass (LPF) 80Hz ~ Full (-12dB/8ª) Variável

bass boost 0 ~ 10,5dB (50Hz)

Thermal Management Smart Cooler (Cooler acionado por temperatura ou áudio em 3 velocidades

Input Impedance 10K OHMS

Output Impedance 1 Ohm

protection system Curto na saída / Tensão de alimentação baixa e alta / Proteção térmica

Minimum Supply Voltage 9 VDC

Maximum Supply Voltage 16 VDC

Consumption at rest 1,8 A

Maximum music consumption 60 A

Maximum consumption in sinusoidal signa l 119 A

Dimensions (WxHxD) 228 x 70 x 158mm

Weight 1,80Kg
